POWERTECH 3-Jaw Wedge Type CNC Hydraulic Chuck (Through-Hole)
POWERTECH CNC
POWERTECH 3-Jaw Wedge Type CNC Hydraulic Chuck (Through-Hole)
Heavy duty through-hole high-speed 3-jaw power chuck for modern CNC turning centers.
Key Engineering Highlights:
- Max Speed: Up to 6000 RPM (depend on size 6" to 15")
- Through-Hole Diameter: 45mm to 117mm bar capacity
- Dynamic Grip Force: 30% higher clamping efficiency
- Alloy Steel Body: Case hardened & ultra-precision ground
- Direct Spindle Mounting: A2-5, A2-6, A2-8, A2-11 ISO standard
Technical Specifications & Dimensions
| Model / Size | Plunger Stroke | Jaw Stroke (Dia) | Max Drawbar Pull | Max Clamping Force | Max RPM | Weight |
|---|---|---|---|---|---|---|
| PT-06 (6 Inch) | 12 mm | 5.5 mm | 22.0 kN | 58.0 kN | 6000 RPM | 12.5 kg |
| PT-08 (8 Inch) | 16 mm | 7.4 mm | 35.0 kN | 86.0 kN | 5000 RPM | 22.0 kg |
| PT-10 (10 Inch) | 19 mm | 8.8 mm | 45.0 kN | 112.0 kN | 4200 RPM | 35.0 kg |
| PT-12 (12 Inch) | 23 mm | 10.6 mm | 56.0 kN | 145.0 kN | 3300 RPM | 56.0 kg |
| PT-15 (15 Inch) | 25 mm | 10.6 mm | 72.0 kN | 180.0 kN | 2500 RPM | 98.0 kg |
